JB3030 Mid-Power LEDs



规格书下载:


JB3030 Mid-Power LEDs

Cree JB3030 Mid-Power LEDs are optimized for applications where mid-power and smooth appearance is critical. The JB3030 mid-power LEDs feature 25ºC flux binned, 85ºC chromaticity binned, 6500K to 2700K ANSI CCTs available, and 5V reverse voltage. These mid-power LEDs operate at -40ºC to 105ºC temperature range and 125ºC LED junction temperature. The JB3030 LEDs come in 3.0mm x 3.0mm x 0.5mm dimensions which are industry compatible size. These LEDs are UL recognized component (E495478). Typical applications include troffers, panel, and outdoor area lights.

Features
  • 3.0mm x 3.0mm x 0.5mm industry-compatible size
  • 3-V and 6-V configurations
  • Flux binned at 25°C, chromaticity binned at 85°C
  • 6500 K–2700 K ANSI CCTs available
  • 70, 80, and 90 CRI available for all CCTs
  • RoHS and REACH compliant
  • UL® recognized component (E495478)
  • -40ºC to 125ºC operating temperature
  • 125ºC LED junction temperature
  • 5V reverse voltage
  • 14ºC/W thermal resistance



Cree, Inc.: JK3030AWT-00-0000-000B0HL257E JK3030AWT-00-0000-000A0HL265E JK3030AWT-00-0000-000B0BL235E JK3030AWT-00-0000-000B0UH430E JK3030AWT-00-0000-000B0BK427E JK3030AWT-00-0000-000B0HL245E JB3030AWT-00-0000-000A0BD465E JB3030AWT-00-0000-000A0BD330E JB3030AWT-00-0000-000A0BD457E JK3030AWT-00-0000-000A0HL257E JB3030AWT-00-0000-000A0BD445E JB3030AWT-00-0000-000A0UC565E JK3030AWT-00-0000-000A0HL250E JB3030AWT-00-0000-000A0HD365E JK3030AWT-00-0000-000B0BL457E JK3030AWT-00-0000-000B0HL250E JB3030AWT-00-0000-000A0UC557E JK3030AWT-00-0000-000B0BL450E JK3030AWT-00-0000-000B0BL440E JB3030AWT-00-0000-000A0HD345E JK3030AWT-00-0000-000B0HK435E JK3030AWT-00-0000-000A0BL235E JK3030AWT-00-0000-000B0UJ235E JK3030AWT-00-0000-000A0UJ465E JK3030AWT-00-0000-000A0UJ235E JB3030AWT-00-0000-000A0HD230E JB3030AWT-00-0000-000A0UC327E JB3030AWT-00-0000-000A0UC430E JK3030AWT-00-0000-000A0UJ445E JB3030AWT-00-0000-000A0HC527E JK3030AWT-00-0000-000B0BL445E JK3030AWT-00-0000-000B0BK430E JK3030AWT-00-0000-000A0UH430E JK3030AWT-00-0000-000B0HL240E JK3030AWT-00-0000-000B0HK230E JB3030AWT-00-0000-000A0HD357E JK3030AWT-00-0000-000A0HL245E JB3030AWT-00-0000-000A0UC545E JK3030AWT-00-0000-000B0UJ445E JK3030AWT-00-0000-000A0BL440E JB3030AWT-00-0000-000A0HD350E JB3030AWT-00-0000-000A0BD335E JK3030AWT-00-0000-000A0UH427E JK3030AWT-00-0000-000B0BL465E JK3030AWT-00-0000-000A0UJ440E JK3030AWT-00-0000-000B0HL265E JK3030AWT-00-0000-000A0BK430E JB3030AWT-00-0000-000A0BD440E JB3030AWT-00-0000-000A0UC540E JK3030AWT-00-0000-000A0HK230E JK3030AWT-00-0000-000A0HK227E JK3030AWT-00-0000-000B0UH427E JK3030AWT-00-0000-000A0BL465E JK3030AWT-00-0000-000B0UJ440E JK3030AWT-00-0000-000A0HK435E JK3030AWT-00-0000-000A0BL445E JK3030AWT-00-0000-000A0BL457E JB3030AWT-00-0000-000A0HD235E JK3030AWT-00-0000-000A0HL240E JK3030AWT-00-0000-000B0HK227E JK3030AWT-00-0000-000A0UJ457E JK3030AWT-00-0000-000A0BK427E JB3030AWT-00-0000-000A0BD227E JK3030AWT-00-0000-000B0UJ450E JK3030AWT-00-0000-000A0BL450E JK3030AWT-00-0000-000B0UJ457E JK3030AWT-00-0000-000B0UJ465E JB3030AWT-00-0000-000A0UC550E JK3030AWT-00-0000-000A0UJ450E JB3030AWT-00-0000-000A0UC435E JB3030AWT-00-0000-000A0BD450E JB3030AWT-00-0000-000A0HD340E
