Product performance of LUXEON SunPlus CoB Line at specified test current, Tj=85°C.
| PRODUCT | COLOR | PPF (μmol/s) in PAR (400 to 700nm) | TEST CURRENT (MA) | LES (MM) | PART NUMBER | |
|---|---|---|---|---|---|---|
| MINIMUM | TYPICAL | |||||
| LUXEON SunPlus CoB 1208 | Purple (12.5% Blue) |
47.70 | 53.00 | 900 | 15 | L2C5-SPP11208E1500 |
| LUXEON SunPlus CoB 1211 | 63.90 | 71.00 | 1200 | 19 | L2C5-SPP11211E1900 | |
| LUXEON SunPlus CoB 1825 | 179.10 | 199.00 | 2250 | 32 | L2C5-SPP11825G3200 | |
| LUXEON SunPlus CoB 1825 | Rose | 180.00 | 200.00 | 2250 | 32 | L2C5-SPR11825G3200 |
