LUXEON 5050 L150



规格书下载: https://www.mouser.cn/datasheet/2/602/DS174_luxeon_5050_datasheet-1892167.pdf

LUXEON 5050 是多晶粒高功率封装 LED,可通过单个封装提供高照度,实现具有成本效益的单光定向灯设计。LUXEON 5050 采用行业标准 5050 表面安装封装,

具有最小的圆形发光面 (LES)。LUXEON 5050 可提供 70CRI、80CRI 和 90CRI 以及大范围的 CCT,适合暖光应用,可确保 LED 能够在 85°C 的应用环境下提供目标光色。



4



Lumileds:

L150-4070502400000 L150-5770502400000 L150-2790502400000 L150-4080502400000 L150-2780502400000

L150-5070502400000 L150-5080502400000 L150-3090502400000 L150-3070502400000 L150-3080502400000

L150-4090502400000 L150-2770500600000 L150-2780500600000 L150-5090500600000 L150-3570500600000

L150-4080500600000 L150-5790500600000 L150-3570502400000 L150-3580502400000 L150-3590500600000

L150-6570502400000 L150-6580502400000 L150-2270500600000 L150-3080500600000 L150-5780500600000

L150-2270502400000 L150-4090500600000 L150-5070500600000 L150-5090502400000 L150-6570500600000

L150-6580500600000 L150-2280500600000 L150-3590502400000 L150-2280502400000 L150-3070500600000

L150-4070500600000 L150-2790500600000 L150-5080500600000 L150-5770500600000 L150-2770502400000

L150-3580500600000 L150-3090500600000 L150-5780502400000 L150-5790502400000 L150-22705006000S0

L150-22705030000S0 L150-27705006000S0 L150-27705030000S0 L150-30705006000S0 L150-30705030000S0

L150-57705006000S0 L150-57705030000S0 L150-65705006000S0 L150-65705030000S0 L150-35705006000S0

L150-35705030000S0 L150-40705006000S0 L150-40705030000S0 L150-50705006000S0 L150-50705030000S0

L150-57905006000S0 L150-50805030000S0 L150-27905030000S0 L150-50905006000S0 L150-65805030000S0

L150-40905006000S0 L150-40905030000S0 L150-57805006000S0 L150-57805030000S0 L150-27905006000S0

L150-50905030000S0 L150-35905006000S0 L150-35905030000S0 L150-57905030000S0 L150-65805006000S0

L150-30905030000S0 L150-30905006000S0 L150-50805006000S0
